Description
Ultra Slim, Contemporary & Elegant Design
Higher Light Transmission Rate
Exterior shell, cannot be easily damaged
No infrared, does not attract flies
Easy to install
No Lead or Mercury content
Environment friendly
Dimmable options available in selected models
Applications
Office Lighting
Conference Halls
Hospitals
Hotels
Shopping Malls
Showroom and lobby cabin etc.
Kitchen and Domestic Lighting
General Information
LED Chip
SMD
Lifespan
>20 000 hrs
Electrical Data
Wattage
12W
EQ. Wattage
48W
Voltage
AC: 200-240V
Frequency
50/60Hz
Power Factor
>0.7
Light technical data
Light color
White
Color Temperature
6000K
Luminous flux (lm)
1000 lm
Color Rendering Index CRI
>80
Beam angle°
120°
Body details
Material
Aluminium, PMMA, PS
Shape
Round
Type
Recessed
Capabilities
Dimmable
Starting Time 100% ON
0.001 sec (instant on)
Color stability
<6
Luminous intensity, Cd
318.30 Cd Max.
On/Off cycles
15000
Working conditions
Not suitable for use in extreme conditions. Normal working conditions is -20° +45°
IP Rating
IP20
Dimensions
Width
12 mm
Diameter
170 mm
Mounting Size
Ø155 mm
Certificates & standards
Energy efficiency class
A
Certification
CE, EMC, ROHS
Width: 170mm
Depth: 12mm
