Description
Variable speed control.
Spindle lock.
Hex collet nut allows easy cutter changes.
43mm diameter collar removable base for carving, die grinding and pillar drill fitment. Tapped fixing holes for Trend standard guide bushes.
Separate dust spout fixing holes.
Adjustable twin rod side fence for guiding along a straight edge.
Includes special 16mm guide bush for use with hinge jig.
Rating Entry Trade
Voltage 230 volt
Plunge stroke 0-35 mm
Power input 850 watts
Power ampage 3.7 amp
Standard collet dia. 1/4″, 6 mm & 8 mm
Dust spout size ID 34 mm
Guide bush dia. 16 mm
No load speeds 11500 – 32000 rpm
Weight 2.8 kg
Cutter dia. max 30 mm
Rod diameter 8 mm
Rod length 300 mm
Rod centres 84 mm
Sound pressure Lpa 85 dB(A)1
Acoustic pressure Lwa 96 dB(A)2
Hand arm vibration <3.0 m/s2
Base size 143 mm x 102 mm
1 x 1/4" Collet, 6mm Collet, 8mm Collet
1 x 34mm Bolt-on Dust Spout
1 x 16mm Guide Bush
1 x Special 16mm Hinge Jig Guide Bush
2 x Spanners
1 x Side-fence
1 x Hex key
1 x Storage Case
