Description
Variable speed control.
Spindle lock.
Hex collar nut allows easy cutter changes.
43mm diameter collar removable base for carving, die grinding and pillar drill fitment. Tapped fixing holes for Trend standard guide bushes.
Seperate dust spout fixing holes.
Adjustable twin rod side fence for guiding along a straight edge.
Ideal for site use.
Includes special 16mm guide bush for use with hinge jig.
Minimum generator or transformer requirement 2.75 kVA continuous.
For UK sale only.
Rating Entry Trade
Voltage* 115 volt
Plunge stroke 0-35 mm
Power input 850 watt
Power ampage 6.6 amp
Standard collet dia. 1/4″, 6 mm & 8 mm
Dust spout size ID 34 mm
Guide bush dia. 16 mm
No load speeds 11500 – 32000 rpm
Weight 2.8 kg
Cutter dia. max 30 mm
Rod diameter 8 mm
Rod length 300 mm
Rod centres 84 mm
Sound pressure Lpa 85 dB(A)1
Acoustic pressure Lwa 96 dB(A)2
Hand arm vibration <3.0 m/s2
*Min. generator or transformer 2.75 kVA continuous
1 x 1/4" Collet
1 x 6mm Collet
1 x 8mm Collet
1 x 34mm Bolt-on Dust Spout
1 x 16mm Guide Bush
1 x Side-fence
1 x Storage Case
