Description
Suitable for domestic dining, living, bathroom and bedroom spaces, hotel & office reception areas
LED replacement for 50W LV halogen downlights
Colour temperature selectable; switch on the back of the fitting allows selection between 3000/4000/6000K
LEDchroic lens replicating halogen dichroic with uniform, shadow-free light
Complies with BS476 Part 21. Report and certificate from INTERNATIONAL FIRE CONSULTANTS (IFC)
Designed and tested to retain the integrity of 30, 60 and 90 minute fire rated ceilings – compliant with Building Regulations Parts B, C and E
Shallow profile of only 60mm depth
Prewired with 0.3m of flex
Complete with 3-way double push-in connector block allowing loop in loop out
Chrome and brushed chrome trims available as an accessory
High efficacy of 77-94lm/W
Wide operating ambient temperature range of -20øC to +40øC
Compatible with selected trailing and leading edge dimmers. Compatibility list available on website
Cap Type LED
Total Power (Mkt) 6.8/6.6/6.8
Lumens (lm) (Mkt) 520/610/550
Beam Angle (Mkt) 60
Lamp Life (Hrs) 30000
Number of LEDs 1
Comparable To 50W LV halogen
CRI (Mkt) 80
CCT (K) (Mkt) 3000/4000/6000
Efficacy (lm/cctW) – Mkt 77/94/83
Lux at 1m (Mkt) 670/700/570
Power Factor (Mkt) 0.9
Colour White
Cut Out (mm) 72
Projection (mm) 5
Recess Depth (mm) 55
Depth (mm) 60
Diameter (mm) 85
Unit Weight / kg 0.24
