Description
Perfect sealing of the drill hole without any sealing compound.
Watertightness approved according to ETAG 022 and DIN 18534 up to water exposure class W3-I. In any case, please take note of the general national regulations on the use of plugs in wet areas.
Quick and easy assembly by simply hammering in the plug.
Suitable for all building materials.
High load values due to the 2-component material.
Drill diameter 6 mm
Drill hole diameter tolerance 6 – 6.4 mm
Min. drill hole depth 65 – tfix mm
Min. building material thickness 22 mm
Anchor length 38 mm
Screw dimension 4.5 x 60 mm
Drive TX20
Sealing depth 5 – 14 mm
Tile thickness 5 – 10 mm
Max. fixture thickness 12 mm
Contents 50 x DuoSeal 6 x 38, 50 x Panhead sealing screw4,5 x 60 A2
