Description
Material – Galvanized Mild Steel DX51D+Z275 to EN10346:2015
Coating/Finish/Colour – 275g/m² Zinc Coating
Length 1/Projection – 32mm Projection
Length 2/height – 117.5mm
Width/Wing Length – 114.3mm
Material Gauge – 0.9mm
Individual Weight (kg) – 0.083
Declared Loadbearing Capacity – 1.6kN (ULS) Uplift
Fire Rating – Euroclass A1
Fixing Hole Dimensions – 3.8mm
Fixing Type – 3.75 x 30mm Square Twisted Sherardized/Galvanised Nails
Installation requirement 1 – All nail holes must be filled.
Installation requirement 2 – Wall plate must be securely fixed down to the supporting masonry with restraint straps or similar.
